Features and functions

Full-wave sampling, full-waveform recording of one potential data, real-time monitoring of self-electric interference, and secondary calculation of polarization rate based on full-waveform potential;

Accurate measurement-The system step response self-calibration technology is adopted, which has strong anti-interference ability, accurate power-off delay, and more accurate polarization measurement;

Precise synchronization support software synchronization, quartz clock synchronization, GPS synchronization. Software synchronization can accommodate all time-domain IP launch systems at home and abroad; the quartz clock and GPS synchronization measurement speed is fast, and it is more suitable for areas with weak signals or strong interference;

Lightweight and reliable-P67 waterproof grade, small size and light weight.

Main Specifications

Synchronization mode: software synchronization, GPS synchronization, quartz clock synchronization

Potential recording method: full waveform recording

Measuring voltage range 40V (32 bit A/D)

Measurement voltage resolution: 5nV

Apparent susceptibility measurement accuracy: relative error ±0.2%

Input impedance: 50mΩ

Suppression of 50h power frequency interference: ≥120db

Sp compensation: ±40V full range real-time automatic tracking number

Compensation display: 5-inch 24-bit true color LCD, 100cd/?

Data storage: 864G optional, USB2.0 high-speed transmission

Built-in battery: 16.8V7.8h, can work continuously for 23 hours

Working environment: 20℃～+60℃, 95%H

Dimensions: 240×95×240mm

Weight: 1.5kg
